شاشة عرض خارجية أفقية 55 بوصة – IP55Outdoor Landscape Display Screen – 55 inch – IP55
شاشة خارجية أفقية عالية السطوع بحماية IP55 وزجاج مقسّى مقاوم للانفجار، مع تحكم تلقائي في السطوع والتبريد.
A high-brightness landscape outdoor display with IP55 protection, explosion-resistant tempered glass, automatic brightness control, and smart cooling.
المقاسSize55 inch
الدقةResolution1920 × 1080
السطوعBrightness2000 nits
الحمايةProtectionIP55
النظامOSAndroid 7.1+
التكوينConfig.Up to 8GB + 128GB
المواصفات الفنية · Technical specifications
المواصفات باللغة العربيةالجدول الأول
| مساحة العرض | 1209 × 680 mm |
|---|---|
| نسبة العرض | 16:9 |
| التباين | 1200:1 |
| زاوية الرؤية | 178° horizontal × 178° vertical |
| المعالج | RK3288 / RK3568 |
| الذاكرة | 2 GB DDR standard; 4/8 GB optional |
| التخزين | 16 GB Flash standard; 32/64/128 GB optional |
| المنافذ | USB 2.0 ×4, RJ45 ×1 |
| واجهة الفيديو | LVDS / HDMI output |
| الزجاج الواقي | 6 mm tempered explosion-proof glass |
| التحكم في السطوع | Automatic light-sensing system |
| قدرة الصوت | 8 ohms, 2 × 10 W |
| نظام التبريد | Automatic temperature-sensing stepless-speed smart fan |
| حرارة التشغيل | -30°C to 50°C |
| رطوبة التشغيل | 5%-90% |
| العمر التشغيلي | 50,000 hours |
| مصدر الطاقة | 220V |
| القدرة | 400 W |
| الغلاف المعدني | صفائح فولاذية مجلفنة SGCC بسماكة 1.5 مم، بطبقة داخلية غنية بالزنك وطبقة خارجية. |
| عمر الغلاف | >10 years, as stated |
| أداء الزجاج | يتفتت عند الكسر إلى أجزاء صغيرة غير حادة تشبه خلايا النحل. |
| الحماية الكهربائية | Leakage, overcurrent, and overvoltage protection |
| التحكم الزمني | Start and stop controlled by time period and week |
| الحماية من الصواعق | Level C |
| مزوّدات الطاقة | Taiwan power supplies, as stated |
| المراوح | Imported axial fans with intelligent speed and timer control |
| السخان | PTC heating module |
| الوزن الكلي | 100 kg |
| أبعاد التغليف | 2130 (L) × 540 (W) × 1040 (H) mm, landscape |
Specifications in EnglishSecond table
| Display area | 1209 × 680 mm |
|---|---|
| Aspect ratio | 16:9 |
| Contrast | 1200:1 |
| Viewing angle | 178° horizontal × 178° vertical |
| CPU | RK3288 / RK3568 |
| RAM | 2 GB DDR standard; 4/8 GB optional |
| Storage | 16 GB Flash standard; 32/64/128 GB optional |
| Interfaces | USB 2.0 ×4, RJ45 ×1 |
| Video interface | LVDS / HDMI output |
| Protective glass | 6 mm tempered explosion-proof glass |
| Brightness control | Automatic light-sensing system |
| Audio power | 8 ohms, 2 × 10 W |
| Cooling system | Automatic temperature-sensing stepless-speed smart fan |
| Operating temperature | -30°C to 50°C |
| Operating humidity | 5%-90% |
| Service life | 50,000 hours |
| Power supply | 220V |
| Power | 400 W |
| Sheet-metal casing | 1.5 mm SGCC galvanized steel sheet with a zinc-rich inner coating and an outer coating. |
| Casing service life | >10 years, as stated |
| Glass performance | When broken, it shatters into small blunt honeycomb-like fragments. |
| Electrical protection | Leakage, overcurrent, and overvoltage protection |
| Timed control | Start and stop controlled by time period and week |
| Lightning protection | Level C |
| Power supplies | Taiwan power supplies, as stated |
| Fans | Imported axial fans with intelligent speed and timer control |
| Optional heater | PTC heating module |
| Total weight | 100 kg |
| Packaging dimensions | 2130 (L) × 540 (W) × 1040 (H) mm, landscape |
كاتالوج DATA SHEET
55 بوصة – IP55 Outdoor Landscape Display ScreenPDF • 4.3 ميغابايتتحميل
